24口千兆（万兆上联）三层汇聚型交换机
utp7624gs-l3
- 产品描述
- 产品规格
- 产品尺寸
- 产品应用
- 产品清单
- 关联下载
- 关联视频
.jpg)
|
型号 |
utp7624gs-l3 |
|
sfp 千兆光口 |
24*1000 base-x sfp(mini-gbic) |
|
电口 |
8* 10/100/1000base-t poe rj45(auto-mdi/mdi-x) combo |
|
sfp 万兆光口 |
4*1000/10g base-x sfp |
|
console 端口 |
1*rj45-r232 serial port(115200,8,n,1) |
|
oob 端口 |
1*10/100base-tx rj45(仅用于登录web管理) |
|
默认ipip:192.168.1.200 name:admin password:admin) |
|
|
init 按键 |
短按重启 |
|
>5s 长按恢复出厂设置 |
|
|
网络标准 |
ieee802.3 、ieee802.3u、ieee802.3ab、ieee802.3z、ieee802.3x、 ieee 802.1q ieee 802.1p ieee 802.3ad 、 ieee 802.1d、ieee 802.1x |
|
交换容量 |
256gbps / 无阻塞 |
|
包转发率 |
95.2mpps |
|
交换方式 |
存储转发 |
|
包数据缓存 |
12mbit |
|
mac地址表 |
16k |
|
最大帧 |
10k bytes |
|
浪涌保护 |
6kv execute：iec61000-4-5 |
|
esd保护 |
6kv contact discharge |
|
8kv air discharge |
|
|
execute：iec61000-4-2 |
|
|
电源模块 |
输入100~240vac 50/60hz自适应，输出dc12v150w |
|
支持双电源，冗余备份（自带1个电源模块，另1个另外购买） |
|
|
功耗 |
60w |
|
工作温度 |
-10-55℃ |
|
存储温度 |
-40-85℃ |
|
工作湿度（无冷凝） |
5%-95% |
|
尺寸（l×w×h） |
442mm×320mm×44.5mm |
|
净重 |
5.65kg |
|
认证 |
ce、fcc、rohs |
|
软件参数 |
|
|
端口管理 |
support port enabling and disabling |
|
support port speed settings |
|
|
support port full-duplex mode |
|
|
support ieee802.3x flow control |
|
|
support jumbo frame |
|
|
support port name modification |
|
|
vlan |
support of 4k vlan |
|
support 802.1q vlan protocol |
|
|
support qinq |
|
|
support gvrp动态vlan注册 |
|
|
support vlan based on port\protocol\mac |
|
|
qos |
support cos classification base on 802.1p |
|
support qos base on dscp |
|
|
support 8 priority queues |
|
|
queue scheduling: sp, wrr, sp wrr |
|
|
support 802.1p cos/dscp priority |
|
|
多播 |
support snmpv1 / v2 / v3 protocols |
|
support igmp snooping |
|
|
support mld-snooping |
|
|
安全特性 |
supports ip, mac, port, vlan binding combinations |
|
support mac address auto-learning, aging and filtration |
|
|
support port isolation, port speed limit |
|
|
support stp \ rstp \mstp，fast-ring |
|
|
support 5 groups of link aggregation |
|
|
support lldp ,smart-link ,dldp |
|
|
support 802.1x |
|
|
acl |
support base on source-mac、target-mac、protocal-classify、source-ip、target-ip、l4 ports-number |
|
support time-range management |
|
|
系统管理 |
web-based gui and cli management |
|
support ftp / tftp / http load upgrade |
|
|
support traffic statistics |
|
|
support mac address table query |
|
|
support ip address, dns server modifications |
|
|
support user name and password modification |
|
|
support for history, log management |
|
|
support system configuration backup |
|
|
support to recover the default factory settings on reboot |
|
|
l3 管理 |
support ipv4 static route setup |
|
support rip v1/2 on ipv4 |
|
|
support ospf v1/v2 |
|
|
support isis on ipv4 |
|
|
support bgp on ipv4 |
|
|
support static arp add,delete,burn-in time sutup/check |
|
|
support static ndadd,delete,burn-in time sutup/check |
|
|
support vrrp v1/2/3 virtual redundant route protocol |
|
|
support group-brocasting pim,igmp v1/v2/v3,mld(ipv4) |
|
|
support dhcp client,server |
|
|
support relay repeater,dhcp snooping |
|
|
support duplex transfer check mechanism |
|
|
名称 |
数量 |
|
主机 |
1台 |
|
挂耳 |
1对 |
|
ac电源线 |
1条 |
|
用户手册 |
1本 |
